FLAT TYPE UNDERWATER LIGHT - P100 SERIES
For concrete and vinyl pools
FLAT TYPE UNDERWATER LIGHT - P100 SERIES
For concrete and vinyl pools
- Share
Previous
Next
SIMPLE WALL MOUNT WITHOUT NICH
Product Features
Waterproof Standard: IP68
Cable: 2.5m
Installation: Wall Mounted (Flat Type)
Material: ABS + UV Stabilizer
Color
| Key No. | Part No. | Description | Piece(s) Required |
|---|---|---|---|
| 1 | 01221002 | Colour lens (Red+Green+Blue) for P100 | 1 |
| 2 | 03011321 | M5*20 Screw (316#) | 1 |
| 3 | 01051059 | Face Ring | 1 |
| 4 | 01041021 | P100 Lights Lens | 1 |
| 5 | 03021018 | M6 Brass Nut | 8 |
| 6 | 01051058 | P100 Lights Face plate | 1 |
| 7 | 02021004 | O-ring | 1 |
| 8 | E040205 | Halogen light bulb (Yellow Light) | 1 |
| 9 | 89040201 | P100 Lights Body set(with 2.5M cable) | 1 |
| 10 | 03011320 | M6*20 Screw (316#) | 8 |
| 11 | 89040203 | Concrete Pool Fittingfor P100 | 1 |
| 12 | 89044501 | Vinyl Pool Fitting for P100 | 1 |
