EL-NP300 SERIES UNDERWATER LIGHT

For concrete pool and vinyl pool

EL-NP300 SERIES UNDERWATER LIGHT

For concrete pool and vinyl pool

WITH A HIGH STRENGTH PLASTIC NICHE

Emaux’s E-Lumen Underwater Light is the industrial leading Nicheless LED pool and spa light, designed to deliver brilliant and vibrant colors by a single light. The single color options maximize the brightness of your pool. The party themes run through your pool and spa by E-Lumen 6 brilliant rich colors and 8 colors pre-programmed light show. With the best LED technology, Nicheless E-Lumen mounts directly on the wall for simple installation. Only required a few bolts, this is the most convenient choice for professional underwater light.

Product Features

RGB

Waterproof Standard: IP68
Cable:
2.5m
Installation:
Wall Mounted (Housing Type)
Material:
S.S. or Plastic Face Ring Plastic housing

Color

Key No. Part No. Description Piece(s) Required
1 03011326 M6*80 Screws 2
2 03017075 Stainless Steel Lid (EMAUX) 1
2 01050008 Plastic Lid (EMAUX) 1
3 03011327 M6*55 Hexagon Head Screws 6
4 01100011 Compacting Ring 1
5 89045528 Ultra-Thin 252 LED panel 20W,Warm white 1
5 89045529 Ultra-Thin 252 LED panel 20W,Cool white 1
5 89045530 Ultra-Thin 252 LED panel 20W,RGB 1
5 89045531 Ultra-Thin 252 LED panel 20W,Single Blue 1
5 89045522 Ultra-Thin 441 LED panel 35W,Warm white 1
5 89045513 Ultra-Thin 441 LED panel 35W,Cool white 1
5 89045514 Ultra-Thin 441 LED panel 35W,RGB 1
5 89045523 Ultra-Thin 441 LED panel 35W,Single Blue 1
5 89045524 Ultra-Thin 531 LED panel 50W,Warm white 1
5 89045526 Ultra-Thin 531 LED panel 50W,Cool white 1
5 89045527 Ultra-Thin 531 LED panel 50W,RGB 1
5 89045525 Ultra-Thin 531 LED panel 50W,Single Blue 1
6 01051253 fixed position plate 6
7 01230003 Waterproof Cover 1
8 89041602 Nut Fitting 6
9 89041603 Fastening Kit 2
10 89041604 Water Joint Fittings for Cable 1
11 89041608 Vinyl pool fitting for NP300 1
12 01050010 NP300 Lights Niche 1
13 89041605 Plug with O-Ring 1
14 01171106 Joint for wire & pipe 1
